Rated voltage:Uo/U 300/500V
Test voltage:3000V
Insulation resistance at +20° C:≥:(+20°C):≧20MΩx km
Bending radius:
stationary :4 x cable diameterØ
flexible:12.5 x cable diameterØ
Temperature range:
flexible:-5°C - 70°C
stationary:-40°C - 70°C
Radiation resistance:≤80×10cJ/kg
Flame retardant:IEC 60332-1
UL:＜1.5 mm² 300 V (UL+CSA)
＞2.5 mm² 600 V (UL+CSA)
导体导体最大允许温度： +70°C
耐油特点符合DIN VDE 0281-13,HD21.13 S1 以及UL-2587耐油特性要求
| Part No. | No.cores Xcross-sec. mm² |
Outer Øca. mm |
Cop.weight kg / km |
Weight ca. kg / km |
|---|---|---|---|---|
| 114001 | 3G0.5 | 6.1 | 14.4 | 51 |
| 114002 | 4G0.5 | 6.9 | 19.2 | 62 |
| 114003 | 5G0.5 | 7.5 | 24 | 75 |
| 114004 | 7G0.5 | 9 | 33.6 | 117 |
| 114005 | 12G0.5 | 10.7 | 58 | 147 |
| 114006 | 18G0.5 | 12.9 | 86 | 248 |
| 114007 | 25G0.5 | 16 | 120 | 348 |
| 114008 | 3G0.75 | 6.6 | 22 | 61 |
| 114009 | 4G0.75 | 7.3 | 28.8 | 75 |
| 114010 | 5G0.75 | 8.3 | 36 | 100 |
| 114011 | 7G0.75 | 9.8 | 50 | 141 |
| 114012 | 12G0.75 | 12.1 | 86 | 214 |
| 114013 | 18G0.75 | 14 | 130 | 306 |
| 114014 | 25G0.75 | 17.2 | 180 | 427 |
| 114015 | 34G0.75 | 19.5 | 245 | 590 |
| 114016 | 41G0.75 | 21.5 | 296 | 710 |
| 114017 | 50G0.75 | 23.3 | 360 | 807 |
| 114018 | 61G0.75 | 25.8 | 439 | 985 |
| 114019 | 3G1.0 | 7.1 | 28.8 | 71 |
| 114020 | 4G1.0 | 7.7 | 38.4 | 89 |
| 114021 | 5G1.0 | 8.9 | 48 | 116 |
| 114022 | 7G1.0 | 10.4 | 67 | 166 |
| 114023 | 12G1.0 | 12.8 | 115.2 | 251 |
| 114024 | 18G1.0 | 15.2 | 172.8 | 385 |
| 114025 | 25G1.0 | 18.5 | 240 | 534 |
| 114026 | 34G1.0 | 21 | 326.4 | 700 |
| 114027 | 41G1.0 | 22.5 | 394 | 815 |
| 114028 | 50G1.0 | 24.6 | 480 | 993 |
| 114029 | 61G1.0 | 26 | 585.6 | 1173 |
| 114030 | 3G1.5 | 8.4 | 43.2 | 92 |
| 114031 | 4G1.5 | 9.2 | 57.6 | 125 |
| 114032 | 5G1.5 | 10.3 | 72 | 155 |
| 114033 | 7G1.5 | 12.5 | 100.8 | 227 |
| 114034 | 12G1.5 | 15.2 | 172.8 | 330 |
| 114035 | 18G1.5 | 18.3 | 259.2 | 506 |
| 114036 | 25G1.5 | 22.2 | 360 | 700 |
| 114037 | 34G1.5 | 24.6 | 489.6 | 920 |
| 114038 | 41G1.5 | 26.3 | 590 | 1060 |
| 114039 | 50G1.5 | 28.9 | 720 | 1320 |
| 114040 | 61G1.5 | 30.9 | 878.4 | 1560 |
| 114041 | 3G2.5 | 9.9 | 72 | 146 |
| 114042 | 4G2.5 | 11.1 | 96 | 196 |
| 114043 | 5G2.5 | 12.1 | 120 | 235 |
| 114044 | 7G2.5 | 14.7 | 168 | 343 |
| 114045 | 12G2.5 | 17.4 | 288 | 535 |
| 114046 | 25G2.5 | 25.6 | 600 | 1100 |
| 114047 | 34G2.5 | 29.5 | 816 | 1436 |
| 114048 | 50G2.5 | 35 | 1200 | 2070 |
